MD50RE Max Hollow Product Volume: 1.5 L Applicable Raw Materials: PE, PP, PVC, PA... Diehead Amount: 1, 2, 3, 4 Machine Size (LxWxH): 2.65 x 1.8 x 2.15 M Machine Weight: 4 ton Clamping System: Clamping Force: 27 kN Template Distance: 110-280 mm Template Stroke: 170 mm Max Mould Size (WxH): 340 x 260 mm Mould Thickness: 115-160 mm Extrusion System: Screw Diameter: 50 mm Screw L/D Ratio: 25 Plasticizing Capacity (HDPE): 35 Kg/h Screw Heating Zones: 3 Screw Heating Power: 6.3 kW Screw Fan’s Power: 0.42 kW Extrusion Motor’s Power: 11 kW Die Head: Diehead Heating Zones: 2 Diehead Heating Power: 3.5 kW Sprue-die Dia(Max): 60 mm Power Consumption: General Power: 27.5 kW Oil-Pump Motor Power: 5.5 kW Air Pressure: 0.6-0.8 MPa Average Power: 14.3 kW Compressed Air Dosage: 0.4 m³/min Cooling Water Dosage: 30-35 L/min
MD60RE Max Hollow Product Volume: 2.5 L Applicable Raw Materials: PE, PP, PVC, PA... Diehead Amount: 1, 2, 3, 4, 6 Machine Size (LxWxH): 3.23 x 1.96 x 2.3 M Machine Weight: 5.2 ton Clamping System: Clamping Force: 42 kN Template Distance: 120-350 mm Template Stroke: 230 mm Max Mould Size (WxH): 400 x 300 mm Mould Thickness: 125-220 mm Extrusion System: Screw Diameter: 60 mm Screw L/D Ratio: 25 Plasticizing Capacity (HDPE): 68 Kg/h Screw Heating Zones: 3 Screw Heating Power: 9.6 kW Screw Fan’s Power: 0.42 kW Extrusion Motor’s Power: 15 kW Die Head: Diehead Heating Zones: 2 Diehead Heating Power: 4.2 kW Sprue-die Dia(Max): 100 mm Power Consumption: General Power: 36.7 kW Oil-Pump Motor Power: 7.5 kW Air Pressure: 0.6-0.8 MPa Average Power: 23 kW Compressed Air Dosage: 0.4 m³/min Cooling Water Dosage: 40-45 L/min
MD70RE Max Hollow Product Volume: 5 L Applicable Raw Materials: PE, PP, PVC, PA... Diehead Amount: 1, 2, 3, 4, 6, 8 Machine Size (LxWxH): 3.85 x 2.26 x 2.5 M Machine Weight: 7.2 ton Clamping System: Clamping Force: 70 kN Template Distance: 200-540 mm Template Stroke: 340 mm Max Mould Size (WxH): 490 x 370 mm Mould Thickness: 205-280 mm Extrusion System: Screw Diameter: 70 mm Screw L/D Ratio: 25 Plasticizing Capacity (HDPE): 85 Kg/h Screw Heating Zones: 3 Screw Heating Power: 12.4 kW Screw Fan’s Power: 0.42 kW Extrusion Motor’s Power: 22 kW Die Head: Diehead Heating Zones: 2 Diehead Heating Power: 6.5 kW Sprue-die Dia(Max): 130 mm Power Consumption: General Power: 52.4 kW Oil-Pump Motor Power: 11 kW Air Pressure: 0.6-0.8 MPa Average Power: 26.8 kW Compressed Air Dosage: 0.4 m³/min Cooling Water Dosage: 60 L/min
MD80RE Max Hollow Product Volume: 12 L Applicable Raw Materials: PE, PP Diehead Amount: 1, 2, 3, 4, 6, 8 Machine Size (LxWxH): 4.5 x 3.16 x 3.1 M Machine Weight: 9 ton Clamping System: Clamping Force: 107 kN Template Distance: 240-620 mm Template Stroke: 380 mm Max Mould Size (WxH): 580 x 450 mm Mould Thickness: 245-320 mm Extrusion System: Screw Diameter: 80 mm Screw L/D Ratio: 25 Plasticizing Capacity (HDPE): 130 Kg/h Screw Heating Zones: 4 Screw Heating Power: 16 kW Screw Fan’s Power: 0.56 kW Extrusion Motor’s Power: 30 kW Die Head: Diehead Heating Zones: 2 Diehead Heating Power: 13.5 kW Sprue-die Dia(Max): 180 mm Power Consumption: General Power: 78.56 kW Oil-Pump Motor Power: 18.5 kW Air Pressure: 0.6-0.8 MPa Average Power: 40 kW Compressed Air Dosage: 0.8 m³/min Cooling Water Dosage: 70 L/min
